Placa Mãe Gigabyte B450 AORUS M, Chipset B450, AMD AM4, mATX, DDR4

Marca:
Gigabyte

Modelo:
B450 AORUS M

Processador:
Soquete AM4:
Processadores AMD Ryzen 2nd Generation
Processadores AMD Ryzen com Radeon Vega Graphics
Processadores AMD Ryzen 1st Generation

Chipset:
AMD B450

Memória:
4 x soquetes DDR4 DIMM suportando até 64 GB de memória do sistema.
Arquitetura de memória Dual channel
Suporte para módulos de memória DDR4 3200(O.C.)/2933/2667/2400/2133 MHz
Suporte para módulos de memória DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Suporte para módulos de memória DIMM 1Rx8/2Rx8/1Rx16 memory modules
Suporte para módulos de memória com Extreme Memory Profile (XMP)

Slots de Expansão:
1 x PCI Express x16 slot, running at x16 (PCIEX16)(Note)* Para melhor performance, se apenas uma placa gráfica PCI Express estiver instalada, instale no slot PCIEX16. (The PCIEX16 slot conforms to PCI Express 3.0 standard.)
1 x slot PCI Express x16, um x4 (PCIEX4)
1 x slot PCI Express x1 (os slots PCIEX4 e PCI Express x1 estão em conformidade com o padrão PCI Express 2.0).

Multi-GPU SLI/Crossfire:
Suporte para as tecnologias AMD Quad-GPU CrossFire e 2-Way AMD CrossFire

Armazenamento
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support)
6 x conectores SATA de 6 Gb / s
Support for RAID 0, RAID 1, and RAID 10
* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

Portas USB:
2 x USB 3.1 Gen 2 Type-A ports (red) on the back panel
2 x USB 3.1 Gen 1 ports available through the internal USB header
6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
CPU:
4 x USB 3.1 Gen 1 ports on the back panel

Audio:
Realtek® ALC892 codec
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out

LAN (rede):
Realtek® GbE LAN chip (10/100/1000 Mbit)

Conectores internos:
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
2 x system fan headers
1 x M.2 Socket 3 connector
6 x SATA 6Gb/s connectors
1 x CPU cooler LED strip/RGB LED strip header
1 x RGB (RGBW) LED strip header
2 x digital LED strip headers
2 x digital LED strip power select jumpers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.1 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only)
1 x serial port header
1 x parallel port header
1 x Clear CMOS jumper

Portas traseiras:
1 x PS/2 keyboard/mouse port
1 x DVI-D port
1 x HDMI port
2 x USB 3.1 Gen 2 Type-A ports (red)
4 x USB 3.1 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks

Dimensões:
Formato Micro ATX 24,4 cm x 21,5 cm
