DJI Phantom 4 Pro RC Quadcopter

● 1-inch 20MP sensor, mechanical shutter, 4K UHD, H.264 and H.265
● 720P 30fps real-time WiFi FPV, 4.3 mi. ( 7km ) image transmission
● 5 directions of obstacle sensing, 4 directions of obstacle avoidance
● 30min flight time provided by the 5870mAh high-capacity battery
● Easy-to-use DJI GO 4 App offers access to Draw, ActiveTrack, TapFly etc.

Specifications:
AIRCRAFT
Weight ( battery and propellers included ): 1388g
Diagonal size ( propellers excluded ): 350mm
Max. ascent speed: S-mode: 6m/s; P-mode: 5m/s
Max. descent speed: S-mode: 4m/s; P-mode: 3m/s
Max. speed: 45 mph / 72 kph ( S-mode ); 36 mph / 58 kph ( A-mode ); 31 mph / 50 kph ( P-mode )
Max. tilt angle: 42 degree ( S-mode ); 35 degree ( A-mode ); 25 degree ( P-mode )
Max. angular speed: 250 degree/s ( S-mode ); 150 degree/s ( A-mode )
Max. service ceiling above sea level: 19685ft ( 6000m )
Max. flight time: approx. 30 minutes
Operating temperature: 32 to 104 Deg.F / 0 to 40 Deg.C
Satellite positioning systems: GPS / GLONASS
GPS hover accuracy range: vertical: + / -0.1m ( with Vision Positioning ); + / -0.5m ( with GPS Positioning ); horizontal: + / -0.3m ( with Vision Positioning ); + / -1.5m ( with GPS Positioning )

VISION SYSTEM
Vision System: Forward, Backward, Downward Vision System
Velocity range: 31 mph / 50 kph or less at 6.6ft ( 2m ) above ground
Altitude range: 0 - 33ft / 0 - 10m
Operating range: 0 - 33ft / 0 - 10m
Obstacle sensory range 2 - 98ft / 0.7 - 30m
FOV: forward: 60 degree ( horizontal ), + / - 27 degree ( vertical ); backward: 60 degree ( horizontal ), + / - 27 degree ( vertical ); downward: 70 degree ( front and rear ), 50 degree ( left and right )
Detection frequency: forward: 10Hz; backward: 10Hz; downward: 20Hz
Operating environment: surfaces with clear patterns and adequate lighting ( more than 15 lux )

CAMERA
Sensor: 1 inch CMOS
Effective pixels: 20MP
Lens FOV ( field of view ): 84 degree, 8.8mm / 24mm ( 35mm format equivalent ), f/2.8 - f/11 auto focus at 1m to infinity
ISO range: video: 100 - 3200 ( Auto ); 100 - 6400 ( Manual ); photo: 100 - 3200 ( Auto ); 100- 12800 ( Manual )
Mechanical shutter: 8 - 1/2000s
Electronic shutter: 1/2000 - 1/8000s
Max. image size: 5472 x 3648 ( 3:2 aspect ratio ); 4864 x 3648 ( 4:3 aspect ratio ); 5472 x 3078 ( 16:9 aspect ratio )
PIV image size: 4096 x 2160; 3840 x 2160; 2720 x 1530; 1920 x 1080; 1280 x 720
Video recording modes: H.265 and H.264 - C4K: 4096 x 2160; 4K: 3840 x 2160; 2.7K: 2720 x 1530; FHD: 1920 x 1080; HD: 1280 x 720
Video storage bitrate: 100Mbps
Supported file systems: FAT32 ( less than 32GB ); exFAT ( more than 32GB )
Photo: JPEG, DNG ( RAW ), JPEG + DNG
Video: MP4 / MOV ( AVC / H.264; HEVC / H.265 )
Supported SD card: Micro SD with max. capacity of 128GB
Write speed: more than 15MB/s, class 10 or UHS-1 rating required
Operating temperature: 32 to 104 Deg.F ( 0 to 40 Deg.C )

CHARGER
Voltage: 17.4V
Rated power: 100W

GIMBAL
Stabilization: 3-axis ( pitch, roll, yaw )
Controllable range: pitch: -90 to +30 degree
Max. controllable angular speed: pitch: 90 degree/s
Angular control accuracy: + / - 0.02 degree

INFRARED SENSING SYSTEM
Obstacle sensory range 0.6 - 23ft ( 0.2 - 7m )
FOV: 70 degree ( horizontal ), + / - 10 degree ( vertical )
Detection frequency: 10Hz
Operating environment: surfaces with diffuse reflection material, and reflectivity more than 8 percent ( such as wall, trees, human, etc. )

TRANSMITTER
Operating frequency: 2.400 - 2.483GHz and 5.725 - 5.825GHz
Max. transmission distance:
2.400 - 2.483GHz ( unobstructed, free of interference ) - FCC: 4.3 miles ( 7km ); CE: 2.2 miles ( 3.5km ); SRRC: 2.5 miles ( 4km )
5.725 - 5.825GHz ( unobstructed, free of interference ) - FCC: 4.3 miles ( 7km ); CE: 1.2 miles ( 2km ); SRRC: 2.5 miles ( 4km )
Operating temperature: 32 to 104 Deg.F / 0 to 40 Deg.C
Battery: 6000mAh 2S LiPo
Transmitter power ( EIRP ):
2.400 - 2.483GHz - FCC: 26dBm; CE: 17dBm; SRRC: 20dBm; MIC: 17dBm
5.725 - 5.825GHz - FCC: 28dBm; CE: 14dBm; SRRC: 20dBm
Operating voltage: 1.2A at 7.4V
Video output port: GL300E: HDMI, USB; GL300F: USB

INTELLIGENT FLIGHT BATTERY
Capacity: 5870mAh
Voltage: 15.2V
Battery type: 4S LiPo
Energy: 89.2Wh
Net weight: 468g
Charging temperature range: 14 to 104 Deg.F / -10 to 40 Deg.C
Max. charging power: 100W
